Magento 2 Composer Module Update

People often asks us how to do a Magento 2 Composer Module Update for their extensions whenever they want to release a new version of their modules.

There are different ways of doing it, we will show you how to do with with git tags and a semantic versioning strategy for the releases, which we thing is the most professional and reliable way.

We will continue with the example of our previous post where we showed you how to create a hello world extension in Magento 2 with composer.

For the newcomers to composer, et me quickly give you an brief explanation of how does it work, more specifically, how we use it together with Magento 2 while developing new modules:

  • To install a new extension developed by ourselves (or by a third party): We normally use “composer require vendor-name/extension-name” from the root folder of Magento 2. Which, by default (depending on the value we’ve set for “minimum-stability” and “prefer-stable” in our composer.json file) will attempt to install the latest version of that extension that meets its dependencies/requirements within your system/application. This means that, for example, if you are using php 5.5.x and the latest version of the extension that you are installing has a dependency (composer.json “require” section) like:
    "php":">=5.6"

    Then, the latest version of the extension cannot be installed on your system. Composer will firstly try to install a newer version of the dependency, and failing that, will search backwards previous versions of the extension until it finds the most recent version that works with php 5.5. Eventually, it will fail if it cannot find any version installable (that meets all the dependencies) in your system . Normally, you just run the command and everything runs smoothly, composer will take care of everything from you, but sometimes it will fail with an error like below:

    composer require lumbrales-software/magento2-first-module
    Using version dev-master for lumbrales-software/magento2-first-module
    ./composer.json has been updated
    Loading composer repositories with package information
    Updating dependencies (including require-dev)
    Your requirements could not be resolved to an installable set of packages.

      Problem 1
        - magento/project-community-edition dev-master requires magento/product-community-edition 2.0.2 -> no matching package found.
        - magento/project-community-edition 2.0.2 requires magento/product-community-edition 2.0.2 ->  no matching package found.
        - magento/project-community-edition 2.0.1 requires magento/product-community-edition 2.0.1 ->  no matching package found.
        - magento/project-community-edition 2.0.0-rc2 requires magento/product-community-edition 2.0.0-rc2 ->  no matching package found.


    This can sometimes require a system update, or like in the above example, adding a custom repository where composer can find the required package.

  • To release a new version (code changes) of your extension: This is the interesting part. People are usually confused and run “composer update” and expect it to do the job, but the problem is that the above command can often lead to undesired and unexpected results, since it will try to update every single package, which is not always (almost never) what we want. Normally, you want to update an specific package, or maybe even a whole vendor, but not everything at once. Therefore, we recommend to tell composer what to do, like in the example of our previous post:
    # Update an specific package
    composer update lumbrales-software/magento2-first-module
    # Update all packages of the vendor
    composer update lumbrales-software/*


Having said that, now let’s focus on how to release a new version of our extension.

The process is actually simpler than it might seem, all you have to do is implement your new functionality, code changes, whatsoever, using whichever git branching strategy you want, and once you are ready, you can do the following steps:

  • Merge your changes into the master branch
  • Choose a version for the update/release, following the guidelines of semantic versioning:
    Given a version number MAJOR.MINOR.PATCH, increment the:

    1. MAJOR version when you make incompatible API changes,
    2. MINOR version when you add functionality in a backwards-compatible manner, and
    3. PATCH version when you make backwards-compatible bug fixes.

    Additional labels for pre-release and build metadata are available as extensions to the MAJOR.MINOR.PATCH format.
    Note: If you want to release a stable version, it has to be at least 1.0.0, otherwise it will be considered unstable by composer and might lead to issues while installing it.

  • Update your composer.json with the new version (ie. “version”: “1.0.1”,) and commit the changes of the file.
  • Create a git tag with the new version:
    git tag 1.0.1
  • Push the changes and the tag:
    git push origin master
    git push --tag
  • That’s it! Now, you should be able to run composer update your-vendor/your-module and it will fetch your changes:
composer update lumbrales-software/magento2-first-module -v
Loading composer repositories with package information
Reading composer.json of lumbrales-software/magento2-first-module (1.0.2)
Importing tag 1.0.2 (1.0.2.0)
Reading composer.json of lumbrales-software/magento2-first-module (1.0.1)
Importing tag 1.0.1 (1.0.1.0)
Reading composer.json of lumbrales-software/magento2-first-module (master)
Importing branch master (dev-master)
Updating dependencies (including require-dev)
  - Removing lumbrales-software/magento2-first-module (1.0.1)
  - Installing lumbrales-software/magento2-first-module (1.0.2)
    Downloading: 100%
    Extracting archive

Writing lock file
Generating autoload files

Note: Sometimes composer seems to keep cached the repository changes and won’t fetch your new code changes, I found a workaround for that by clearing the cache with the below command (run it as your own risk):

rm -fr ~/.composer/cache/*

That’s about it, you now should be able to release code changes nicely, and for every new code changes you just need to bump the version accordingly and remember to push both the version update in the composer.json and the git tag.

Good luck!

Let us know if you have any issues with it and we’ll try to assist you.

Fast scroll in ListView

Fast scroll in ListView

Sometimes when the list is very big, We need to make a fast scroll view. FastScroll is something like that:

Now we leart how to make a fast scroll in listView.
We need these things:

-Style in values-v14.
-Style.
-Colors.
-Layout.
-An adapter for list.
-Activity.

in directory values-v14/styles.xml we have to add three things:
fastScrollThumbDrawable
fastScrollTextColor
fastScrollPreviewBackgroundRight

<?xml version="1.0" encoding="utf-8"?>
<resources>

    <style name="AppTheme" parent="android:Theme.Holo.Light.DarkActionBar">
        <!-- API 14 theme customizations can go here. -->
        <item name="android:fastScrollThumbDrawable">@drawable/fastscroll_thumb_holo</item>
        <item name="android:fastScrollTextColor">@android:color/white</item>
        <item name="android:fastScrollPreviewBackgroundRight">@color/apptheme_color</item>
    </style>

</resources>

In directory values/styles.xml

<resources>

    <!-- Base application theme. -->
    <style name="AppTheme" parent="Theme.AppCompat.Light.DarkActionBar">
        <!-- Customize your theme here. -->
        <item name="colorPrimary">@color/colorPrimary</item>
        <item name="colorPrimaryDark">@color/colorPrimaryDark</item>
        <item name="colorAccent">@color/colorAccent</item>
        <item name="android:fastScrollThumbDrawable">@drawable/fastscroll_thumb_holo</item>
        <item name="android:fastScrollTextColor">@android:color/white</item>
        <item name="android:fastScrollPreviewBackgroundRight">@color/apptheme_color</item>
    </style>

</resources>

In Colors we have to add one color:

<?xml version="1.0" encoding="utf-8"?>
<resources>
    <color name="colorPrimary">#3F51B5</color>
    <color name="colorPrimaryDark">#303F9F</color>
    <color name="colorAccent">#FF4081</color>
    <color name="apptheme_color">#DA4A38</color>
</resources>

In activity_layout our listView.

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context="com.example.javier.fastscrollerwithandroidstyle.MainActivity">

    <ListView
        android:id="@+id/activity_main_list"
        android:layout_width="fill_parent"
        android:layout_height="fill_parent"
        android:scrollbarStyle="outsideOverlay" />
</RelativeLayout>

Our ListAdapter

public class ListAdapter extends ArrayAdapter<String> implements SectionIndexer {

    HashMap<String, Integer> mapIndex;
    String[] sections;
    List<String> fruits;

    public ListAdapter(Context context, List<String> fruitList) {
        super(context, R.layout.list_item, fruitList);

        this.fruits = fruitList;
        mapIndex = new LinkedHashMap<String, Integer>();

        for (int x = 0; x < fruits.size(); x++) {
            String fruit = fruits.get(x);
            String ch = fruit.substring(0, 1);
            ch = ch.toUpperCase(Locale.US);

            // HashMap will prevent duplicates
            mapIndex.put(ch, x);
        }

        Set<String> sectionLetters = mapIndex.keySet();

        // create a list from the set to sort
        ArrayList<String> sectionList = new ArrayList<String>(sectionLetters);

        Log.d("sectionList", sectionList.toString());
        Collections.sort(sectionList);

        sections = new String[sectionList.size()];

        sectionList.toArray(sections);
    }

    public int getPositionForSection(int section) {
        Log.d("section", "" + section);
        return mapIndex.get(sections[section]);
    }

    public int getSectionForPosition(int position) {
        Log.d("position", "" + position);
        return 0;
    }

    public Object[] getSections() {
        return sections;
    }
}

In our activity

public class MainActivity extends Activity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        ListView listView = (ListView) findViewById(R.id.activity_main_list);
        listView.setFastScrollEnabled(true);
        String[] fruits = getResources().getStringArray(R.array.fruits_array);

        List<String> fruitList = Arrays.asList(fruits);
        ListAdapter listAdapter = new ListAdapter(this, fruitList);
        listView.setAdapter(listAdapter);

    }
}

And in our strings, something like that:

<resources>
    <string name="app_name">FastScrollerWithAndroidStyle</string>
    <string-array name="fruits_array">
        <item>Apples</item>
        <item>Apricots</item>
        <item>Avocado</item>
        <item>Annona</item>
        <item>Banana</item>
        <item>Bilberry</item>
        <item>Blackberry</item>
        <item>Custard Apple</item>
        <item>Clementine</item>
        <item>Cantalope</item>
        <item>Coconut</item>
        <item>Currant</item>
        <item>Cherry</item>
        <item>Cherimoya</item>
        <item>Date</item>
        <item>Damson</item>
        <item>Durian</item>
        <item>Elderberry</item>
        <item>Fig</item>
        <item>Feijoa</item>
        <item>Grapefruit</item>
        <item>Grape</item>
        <item>Gooseberry</item>
        <item>Guava</item>
        <item>Honeydew melon</item>
        <item>Huckleberry</item>
        <item>Jackfruit</item>
        <item>Juniper Berry</item>
        <item>Jambul</item>
        <item>Jujube</item>
        <item>Kiwi</item>
        <item>Kumquat</item>
        <item>Lemons</item>
        <item>Limes</item>
        <item>Lychee</item>
        <item>Mango</item>
        <item>Mandarin</item>
        <item>Mangostine</item>
        <item>Nectaraine</item>
        <item>Orange</item>
        <item>Olive</item>
        <item>Prunes</item>
        <item>Pears</item>
        <item>Plum</item>
        <item>Pineapple</item>
        <item>Peach</item>
        <item>Papaya</item>
        <item>Passionfruit</item>
        <item>Pomegranate</item>
        <item>Pomelo</item>
        <item>Raspberries</item>
        <item>Rock melon</item>
        <item>Rambutan</item>
        <item>Strawberries</item>
        <item>Sweety</item>
        <item>Salmonberry</item>
        <item>Satsuma</item>
        <item>Tangerines</item>
        <item>Tomato</item>
        <item>Ugli</item>
        <item>Watermelon</item>
        <item>Woodapple</item>
    </string-array>
</resources>



Rounded Coners With Glide

Rounded Coners With Glide

We start use Glide library, which is a fast and efficient open source media management and image loading framework for Android that wraps media decoding, memory and disk caching, and resource pooling into a simple and easy to use interface.

Now we will learn how to rounded corners with this library.

The first step if we use this library it is that we should to add in our dependencies:

compile 'com.github.bumptech.glide:glide:3.7.0'

Now we will learn how to rounded corners with this library.

The first step.

import android.content.Context;
import android.graphics.Bitmap;
import android.graphics.BitmapShader;
import android.graphics.Canvas;
import android.graphics.Paint;
import android.graphics.RectF;
import android.graphics.Shader;

import com.bumptech.glide.Glide;
import com.bumptech.glide.load.Transformation;
import com.bumptech.glide.load.engine.Resource;
import com.bumptech.glide.load.engine.bitmap_recycle.BitmapPool;
import com.bumptech.glide.load.resource.bitmap.BitmapResource;

/**
 * Created by javiergonzalezcabezas on 2/4/16.
 */
public class RoundedCornersTransformation implements Transformation<Bitmap> {

    public enum CornerType {
        ALL,
        TOP_LEFT, TOP_RIGHT, BOTTOM_LEFT, BOTTOM_RIGHT,
        TOP, BOTTOM, LEFT, RIGHT,
        OTHER_TOP_LEFT, OTHER_TOP_RIGHT, OTHER_BOTTOM_LEFT, OTHER_BOTTOM_RIGHT,
        DIAGONAL_FROM_TOP_LEFT, DIAGONAL_FROM_TOP_RIGHT
    }

    private BitmapPool mBitmapPool;
    private int mRadius;
    private int mDiameter;
    private int mMargin;
    private CornerType mCornerType;

    public RoundedCornersTransformation(Context context, int radius, int margin) {
        this(context, radius, margin, CornerType.ALL);
    }

    public RoundedCornersTransformation(BitmapPool pool, int radius, int margin) {
        this(pool, radius, margin, CornerType.ALL);
    }

    public RoundedCornersTransformation(Context context, int radius, int margin,
                                        CornerType cornerType) {
        this(Glide.get(context).getBitmapPool(), radius, margin, cornerType);
    }

    public RoundedCornersTransformation(BitmapPool pool, int radius, int margin,
                                        CornerType cornerType) {
        mBitmapPool = pool;
        mRadius = radius;
        mDiameter = mRadius * 2;
        mMargin = margin;
        mCornerType = cornerType;
    }

    @Override
    public Resource<Bitmap> transform(Resource<Bitmap> resource, int outWidth, int outHeight) {
        Bitmap source = resource.get();

        int width = source.getWidth();
        int height = source.getHeight();

        Bitmap bitmap = mBitmapPool.get(width, height, Bitmap.Config.ARGB_8888);
        if (bitmap == null) {
            bitmap = Bitmap.createBitmap(width, height, Bitmap.Config.ARGB_8888);
        }

        Canvas canvas = new Canvas(bitmap);
        Paint paint = new Paint();
        paint.setAntiAlias(true);
        paint.setShader(new BitmapShader(source, Shader.TileMode.CLAMP, Shader.TileMode.CLAMP));
        drawRoundRect(canvas, paint, width, height);
        return BitmapResource.obtain(bitmap, mBitmapPool);
    }

    private void drawRoundRect(Canvas canvas, Paint paint, float width, float height) {
        float right = width - mMargin;
        float bottom = height - mMargin;

        switch (mCornerType) {
            case ALL:
                canvas.drawRoundRect(new RectF(mMargin, mMargin, right, bottom), mRadius, mRadius, paint);
                break;
            case TOP_LEFT:
                drawTopLeftRoundRect(canvas, paint, right, bottom);
                break;
            case TOP_RIGHT:
                drawTopRightRoundRect(canvas, paint, right, bottom);
                break;
            case BOTTOM_LEFT:
                drawBottomLeftRoundRect(canvas, paint, right, bottom);
                break;
            case BOTTOM_RIGHT:
                drawBottomRightRoundRect(canvas, paint, right, bottom);
                break;
            case TOP:
                drawTopRoundRect(canvas, paint, right, bottom);
                break;
            case BOTTOM:
                drawBottomRoundRect(canvas, paint, right, bottom);
                break;
            case LEFT:
                drawLeftRoundRect(canvas, paint, right, bottom);
                break;
            case RIGHT:
                drawRightRoundRect(canvas, paint, right, bottom);
                break;
            case OTHER_TOP_LEFT:
                drawOtherTopLeftRoundRect(canvas, paint, right, bottom);
                break;
            case OTHER_TOP_RIGHT:
                drawOtherTopRightRoundRect(canvas, paint, right, bottom);
                break;
            case OTHER_BOTTOM_LEFT:
                drawOtherBottomLeftRoundRect(canvas, paint, right, bottom);
                break;
            case OTHER_BOTTOM_RIGHT:
                drawOtherBottomRightRoundRect(canvas, paint, right, bottom);
                break;
            case DIAGONAL_FROM_TOP_LEFT:
                drawDiagonalFromTopLeftRoundRect(canvas, paint, right, bottom);
                break;
            case DIAGONAL_FROM_TOP_RIGHT:
                drawDiagonalFromTopRightRoundRect(canvas, paint, right, bottom);
                break;
            default:
                canvas.drawRoundRect(new RectF(mMargin, mMargin, right, bottom), mRadius, mRadius, paint);
                break;
        }
    }

    private void drawTopLeftRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, mMargin, mMargin + mDiameter, mMargin + mDiameter),
                mRadius, mRadius, paint);
        canvas.drawRect(new RectF(mMargin, mMargin + mRadius, mMargin + mRadius, bottom), paint);
        canvas.drawRect(new RectF(mMargin + mRadius, mMargin, right, bottom), paint);
    }

    private void drawTopRightRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(right - mDiameter, mMargin, right, mMargin + mDiameter), mRadius,
                mRadius, paint);
        canvas.drawRect(new RectF(mMargin, mMargin, right - mRadius, bottom), paint);
        canvas.drawRect(new RectF(right - mRadius, mMargin + mRadius, right, bottom), paint);
    }

    private void drawBottomLeftRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, bottom - mDiameter, mMargin + mDiameter, bottom),
                mRadius, mRadius, paint);
        canvas.drawRect(new RectF(mMargin, mMargin, mMargin + mDiameter, bottom - mRadius), paint);
        canvas.drawRect(new RectF(mMargin + mRadius, mMargin, right, bottom), paint);
    }

    private void drawBottomRightRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(right - mDiameter, bottom - mDiameter, right, bottom), mRadius,
                mRadius, paint);
        canvas.drawRect(new RectF(mMargin, mMargin, right - mRadius, bottom), paint);
        canvas.drawRect(new RectF(right - mRadius, mMargin, right, bottom - mRadius), paint);
    }

    private void drawTopRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, mMargin, right, mMargin + mDiameter), mRadius, mRadius,
                paint);
        canvas.drawRect(new RectF(mMargin, mMargin + mRadius, right, bottom), paint);
    }

    private void drawBottomRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, bottom - mDiameter, right, bottom), mRadius, mRadius,
                paint);
        canvas.drawRect(new RectF(mMargin, mMargin, right, bottom - mRadius), paint);
    }

    private void drawLeftRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, mMargin, mMargin + mDiameter, bottom), mRadius, mRadius,
                paint);
        canvas.drawRect(new RectF(mMargin + mRadius, mMargin, right, bottom), paint);
    }

    private void drawRightRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(right - mDiameter, mMargin, right, bottom), mRadius, mRadius,
                paint);
        canvas.drawRect(new RectF(mMargin, mMargin, right - mRadius, bottom), paint);
    }

    private void drawOtherTopLeftRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, bottom - mDiameter, right, bottom), mRadius, mRadius,
                paint);
        canvas.drawRoundRect(new RectF(right - mDiameter, mMargin, right, bottom), mRadius, mRadius,
                paint);
        canvas.drawRect(new RectF(mMargin, mMargin, right - mRadius, bottom - mRadius), paint);
    }

    private void drawOtherTopRightRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, mMargin, mMargin + mDiameter, bottom), mRadius, mRadius,
                paint);
        canvas.drawRoundRect(new RectF(mMargin, bottom - mDiameter, right, bottom), mRadius, mRadius,
                paint);
        canvas.drawRect(new RectF(mMargin + mRadius, mMargin, right, bottom - mRadius), paint);
    }

    private void drawOtherBottomLeftRoundRect(Canvas canvas, Paint paint, float right, float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, mMargin, right, mMargin + mDiameter), mRadius, mRadius,
                paint);
        canvas.drawRoundRect(new RectF(right - mDiameter, mMargin, right, bottom), mRadius, mRadius,
                paint);
        canvas.drawRect(new RectF(mMargin, mMargin + mRadius, right - mRadius, bottom), paint);
    }

    private void drawOtherBottomRightRoundRect(Canvas canvas, Paint paint, float right,
                                               float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, mMargin, right, mMargin + mDiameter), mRadius, mRadius,
                paint);
        canvas.drawRoundRect(new RectF(mMargin, mMargin, mMargin + mDiameter, bottom), mRadius, mRadius,
                paint);
        canvas.drawRect(new RectF(mMargin + mRadius, mMargin + mRadius, right, bottom), paint);
    }

    private void drawDiagonalFromTopLeftRoundRect(Canvas canvas, Paint paint, float right,
                                                  float bottom) {
        canvas.drawRoundRect(new RectF(mMargin, mMargin, mMargin + mDiameter, mMargin + mDiameter),
                mRadius, mRadius, paint);
        canvas.drawRoundRect(new RectF(right - mDiameter, bottom - mDiameter, right, bottom), mRadius,
                mRadius, paint);
        canvas.drawRect(new RectF(mMargin, mMargin + mRadius, right - mDiameter, bottom), paint);
        canvas.drawRect(new RectF(mMargin + mDiameter, mMargin, right, bottom - mRadius), paint);
    }

    private void drawDiagonalFromTopRightRoundRect(Canvas canvas, Paint paint, float right,
                                                   float bottom) {
        canvas.drawRoundRect(new RectF(right - mDiameter, mMargin, right, mMargin + mDiameter), mRadius,
                mRadius, paint);
        canvas.drawRoundRect(new RectF(mMargin, bottom - mDiameter, mMargin + mDiameter, bottom),
                mRadius, mRadius, paint);
        canvas.drawRect(new RectF(mMargin, mMargin, right - mRadius, bottom - mRadius), paint);
        canvas.drawRect(new RectF(mMargin + mRadius, mMargin + mRadius, right, bottom), paint);
    }

    @Override public String getId() {
        return "RoundedTransformation(radius=" + mRadius + ", margin=" + mMargin + ", diameter="
                + mDiameter + ", cornerType=" + mCornerType.name() + ")";
    }
}

In your layout we create a ImageView, something like that:

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context="com.thedeveloperworldisyours.roundedconerswithglide.MainActivity">

    <ImageView
        android:id="@+id/activity_main_image_view"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_centerInParent="true" />
</RelativeLayout>

Now in your activity

import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.widget.ImageView;

import com.bumptech.glide.Glide;

public class MainActivity extends AppCompatActivity {

    public static int sCorner = 15;
    public static int sMargin = 2;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        ImageView imageView = (ImageView) findViewById(R.id.activity_main_image_view);
        Glide.with(this)
                .load("http://thedeveloperworldisyours.com/wp-content/uploads/scareface.jpeg")
                .bitmapTransform(new RoundedCornersTransformation( MainActivity.this,sCorner, sMargin))
                .into(imageView);
    }
}

And your manifest add permission of internet, if you want to get image from internet

<manifest xlmns:android...>
 ...
 <uses-permission android:name="android.permission.INTERNET" />
 <application ...
</manifest>

You can check my example in github

Horizontal ListView on Android

Horizontal ListView on Android

Actually android doesn’t have a listView horizontal. So We will see how to make.

We need these things:
*Activity and layout.
*Adapter and list_item.
*Data object.
*DividerItemDecoration (it divides our item).

As per Android Documentaion recyclerview is the new way to organize the items in listview and to be displayed horizontally.

Advantages:

*Since by using Recyclerview Adapter, ViewHolder pattern is automatically implemented
*Animation is easy to perform
*Many more features

In your dependencies you add this line

compile "com.android.support:recyclerview-v7:23.0.0"

dimens.xml

<resources>
    <!-- Default screen margins, per the Android Design guidelines. -->
    <dimen name="activity_main_horizontal_margin">16dp</dimen>
    <dimen name="activity_main_vertical_margin">16dp</dimen>

    <dimen name="activity_main_height">150dp</dimen>
</resources>

list_item.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:orientation="vertical" android:layout_width="match_parent"
    android:layout_height="match_parent">
    <TextView
        android:id="@+id/item_list_view_text_view"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:padding="@dimen/activity_main_vertical_margin"
        android:text="Large Text"
        android:textAppearance="?android:attr/textAppearanceLarge" />

    <TextView
        android:id="@+id/item_list_view_text_view_two"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:gravity="center"
        android:padding="@dimen/activity_main_vertical_margin"
        android:text="Small Text"
        android:textAppearance="?android:attr/textAppearanceSmall" />
</LinearLayout>

activity_main.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context="com.example.javier.recyclerviewhorizontallistviewtwo.MainActivity">

    <android.support.v7.widget.RecyclerView
        android:id="@+id/activity_main_recyclerview"
        android:layout_width="match_parent"
        android:layout_height="@dimen/activity_main_height"
        android:background="@android:color/darker_gray" />

</RelativeLayout>

Our data
Data.java

public class Data {
    private String mText1;
    private String mText2;

    Data(String text1, String text2){
        mText1 = text1;
        mText2 = text2;
    }

    public String getmText1() {
        return mText1;
    }

    public void setmText1(String mText1) {
        this.mText1 = mText1;
    }

    public String getmText2() {
        return mText2;
    }

    public void setmText2(String mText2) {
        this.mText2 = mText2;
    }
}

DividerItemDecoration.java

package com.example.javier.recyclerviewhorizontallistviewtwo;

import android.content.Context;
import android.content.res.TypedArray;
import android.graphics.Canvas;
import android.graphics.Rect;
import android.graphics.drawable.Drawable;
import android.support.v7.widget.LinearLayoutManager;
import android.support.v7.widget.RecyclerView;
import android.view.View;

/**
 * Created by javierg on 14/03/16.
 */
public class DividerItemDecoration extends RecyclerView.ItemDecoration {
    private static final int[] ATTRS = new int[]{
            android.R.attr.listDivider
    };
    public static final int HORIZONTAL_LIST = LinearLayoutManager.HORIZONTAL;
    public static final int VERTICAL_LIST = LinearLayoutManager.VERTICAL;
    private Drawable mDivider;
    private int mOrientation;
    public DividerItemDecoration(Context context, int orientation) {
        final TypedArray a = context.obtainStyledAttributes(ATTRS);
        mDivider = a.getDrawable(0);
        a.recycle();
        setOrientation(orientation);
    }
    public void setOrientation(int orientation) {
        if (orientation != HORIZONTAL_LIST && orientation != VERTICAL_LIST) {
            throw new IllegalArgumentException("invalid orientation");
        }
        mOrientation = orientation;
    }
    @Override
    public void onDraw(Canvas c, RecyclerView parent) {
        if (mOrientation == VERTICAL_LIST) {
            drawVertical(c, parent);
        } else {
            drawHorizontal(c, parent);
        }
    }
    public void drawVertical(Canvas c, RecyclerView parent) {
        final int left = parent.getPaddingLeft();
        final int right = parent.getWidth() - parent.getPaddingRight();
        final int childCount = parent.getChildCount();
        for (int i = 0; i < childCount; i++) {
            final View child = parent.getChildAt(i);
            final RecyclerView.LayoutParams params = (RecyclerView.LayoutParams) child
                    .getLayoutParams();
            final int top = child.getBottom() + params.bottomMargin;
            final int bottom = top + mDivider.getIntrinsicHeight();
            mDivider.setBounds(left, top, right, bottom);
            mDivider.draw(c);
        }
    }
    public void drawHorizontal(Canvas c, RecyclerView parent) {
        final int top = parent.getPaddingTop();
        final int bottom = parent.getHeight() - parent.getPaddingBottom();
        final int childCount = parent.getChildCount();
        for (int i = 0; i < childCount; i++) {
            final View child = parent.getChildAt(i);
            final RecyclerView.LayoutParams params = (RecyclerView.LayoutParams) child
                    .getLayoutParams();
            final int left = child.getRight() + params.rightMargin;
            final int right = left + mDivider.getIntrinsicHeight();
            mDivider.setBounds(left, top, right, bottom);
            mDivider.draw(c);
        }
    }
    @Override
    public void getItemOffsets(Rect outRect, int itemPosition, RecyclerView parent) {
        if (mOrientation == VERTICAL_LIST) {
            outRect.set(0, 0, 0, mDivider.getIntrinsicHeight());
        } else {
            outRect.set(0, 0, mDivider.getIntrinsicWidth(), 0);
        }
    }
}

CustomRecyclerViewAdapter.java

package com.example.javier.recyclerviewhorizontallistviewtwo;

import android.support.v7.widget.RecyclerView;
import android.util.Log;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.TextView;

import java.util.ArrayList;

/**
 * Created by javierg on 14/03/16.
 */
public class CustomRecyclerViewAdapter extends RecyclerView
        .Adapter<CustomRecyclerViewAdapter
        .DataObjectHolder> {
    private static String LOG_TAG = "MyRecyclerViewAdapter";
    private ArrayList<Data> mDataset;
    private static MyClickListener myClickListener;

    public static class DataObjectHolder extends RecyclerView.ViewHolder
            implements View
            .OnClickListener {
        TextView label;
        TextView dateTime;

        public DataObjectHolder(View itemView) {
            super(itemView);
            label = (TextView) itemView.findViewById(R.id.item_list_view_text_view);
            dateTime = (TextView) itemView.findViewById(R.id.item_list_view_text_view_two);
            Log.i(LOG_TAG, "Adding Listener");
            itemView.setOnClickListener(this);
        }

        @Override
        public void onClick(View v) {
            myClickListener.onItemClick(getPosition(), v);
        }
    }

    public void setOnItemClickListener(MyClickListener myClickListener) {
        this.myClickListener = myClickListener;
    }

    public CustomRecyclerViewAdapter(ArrayList<Data> myDataset) {
        mDataset = myDataset;
    }

    @Override
    public DataObjectHolder onCreateViewHolder(ViewGroup parent,
                                               int viewType) {
        View view = LayoutInflater.from(parent.getContext())
                .inflate(R.layout.list_item, parent, false);

        DataObjectHolder dataObjectHolder = new DataObjectHolder(view);
        return dataObjectHolder;
    }

    @Override
    public void onBindViewHolder(DataObjectHolder holder, int position) {
        holder.label.setText(mDataset.get(position).getmText1());
        holder.dateTime.setText(mDataset.get(position).getmText2());
    }

    public void addItem(Data dataObj, int index) {
        mDataset.add(dataObj);
        notifyItemInserted(index);
    }

    public void deleteItem(int index) {
        mDataset.remove(index);
        notifyItemRemoved(index);
    }

    @Override
    public int getItemCount() {
        return mDataset.size();
    }

    public interface MyClickListener {
        public void onItemClick(int position, View v);
    }
}

Our Activity

package com.example.javier.recyclerviewhorizontallistviewtwo;

import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.support.v7.widget.LinearLayoutManager;
import android.support.v7.widget.RecyclerView;
import android.util.Log;
import android.view.View;

import java.util.ArrayList;

public class MainActivity extends AppCompatActivity {

    private RecyclerView mRecyclerView;
    private RecyclerView.Adapter mAdapter;
    private RecyclerView.LayoutManager mLayoutManager;
    private static String LOG_TAG = "RecyclerViewActivity";

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        mRecyclerView = (RecyclerView) findViewById(R.id.activity_main_recyclerview);
        mRecyclerView.setHasFixedSize(true);


        mLayoutManager = new LinearLayoutManager(this,LinearLayoutManager.HORIZONTAL, false);//new LinearLayoutManager(this);
        mRecyclerView.setLayoutManager(mLayoutManager);


        mAdapter = new CustomRecyclerViewAdapter(getDataSet());
        mRecyclerView.setAdapter(mAdapter);
        RecyclerView.ItemDecoration itemDecoration =
                new DividerItemDecoration(this, LinearLayoutManager.HORIZONTAL);
        mRecyclerView.addItemDecoration(itemDecoration);

        // Code to Add an item with default animation
        //((MyRecyclerViewAdapter) mAdapter).addItem(obj, index);

        // Code to remove an item with default animation
        //((MyRecyclerViewAdapter) mAdapter).deleteItem(index);
    }

    @Override
    protected void onResume() {
        super.onResume();
        ((CustomRecyclerViewAdapter) mAdapter).setOnItemClickListener(new CustomRecyclerViewAdapter.MyClickListener() {
            @Override
            public void onItemClick(int position, View v) {
                Log.i(LOG_TAG, " Clicked on Item " + position);
            }
        });
    }

    private ArrayList<Data> getDataSet() {
        ArrayList results = new ArrayList<Data>();
        for (int index = 0; index < 20; index++) {
            Data obj = new Data("Some Primary Text " + index,
                    "Secondary " + index);
            results.add(index, obj);
        }
        return results;
    }

}

Now We have our horizontal ListView.

How to put image in CollapsingToolbarLayout

How to put image in CollapsingToolbarLayout

Inside of our CollopasingTollbarLayout you can put our Image and Toolbar.

you can check in GitHub

<?xml version="1.0" encoding="utf-8"?>
<android.support.design.widget.CoordinatorLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:fitsSystemWindows="true"
    tools:context="com.thedeveloperworldisyours.imagecollapsingtoolbarlayout.ScrollingActivity">

    <android.support.design.widget.AppBarLayout
        android:id="@+id/app_bar"
        android:layout_width="match_parent"
        android:layout_height="@dimen/app_bar_height"
        android:fitsSystemWindows="true"
        android:theme="@style/AppTheme.AppBarOverlay">

        <android.support.design.widget.CollapsingToolbarLayout
            android:id="@+id/toolbar_layout"
            android:layout_width="match_parent"
            android:layout_height="match_parent"
            android:fitsSystemWindows="true"
            app:contentScrim="?attr/colorPrimary"
            app:layout_scrollFlags="scroll|exitUntilCollapsed">

            <!--image-->
            <ImageView
                android:layout_width="match_parent"
                android:layout_height="match_parent"
                android:src="@drawable/scardface_scrolling"/>

            <!--toolbar-->
            <android.support.v7.widget.Toolbar
                android:id="@+id/toolbar"
                android:layout_width="match_parent"
                android:layout_height="?attr/actionBarSize"
                app:layout_collapseMode="pin"
                app:popupTheme="@style/AppTheme.PopupOverlay" />

        </android.support.design.widget.CollapsingToolbarLayout>
    </android.support.design.widget.AppBarLayout>

    <include layout="@layout/content_scrolling" />

</android.support.design.widget.CoordinatorLayout>

In our content

<?xml version="1.0" encoding="utf-8"?>
<android.support.v4.widget.NestedScrollView xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    app:layout_behavior="@string/appbar_scrolling_view_behavior"
    tools:context="com.thedeveloperworldisyours.imagecollapsingtoolbarlayout.ScrollingActivity"
    tools:showIn="@layout/activity_scrolling">

    <TextView
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_margin="@dimen/text_margin"
        android:text="@string/large_text" />

</android.support.v4.widget.NestedScrollView>

In our activity

public class ScrollingActivity extends AppCompatActivity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_scrolling);
        Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar);
        setSupportActionBar(toolbar);

    }

    @Override
    public boolean onCreateOptionsMenu(Menu menu) {
        // Inflate the menu; this adds items to the action bar if it is present.
        getMenuInflater().inflate(R.menu.menu_scrolling, menu);
        return true;
    }

    @Override
    public boolean onOptionsItemSelected(MenuItem item) {
        // Handle action bar item clicks here. The action bar will
        // automatically handle clicks on the Home/Up button, so long
        // as you specify a parent activity in AndroidManifest.xml.
        int id = item.getItemId();

        //noinspection SimplifiableIfStatement
        if (id == R.id.action_settings) {
            return true;
        }
        return super.onOptionsItemSelected(item);
    }
}
